Spiral corrugated pipe widely used in storm sewers, culvert, agricultural irrigation, Municipal engineering - Civic buried water (rain or sewage) drainage;
Diameter: 300mm - 3600mm
Wall thickness: 1.5mm - 4.2mm
Spiral corrugated pipe widely used in storm sewers, culvert, agricultural irrigation, Municipal engineering - Civic buried water (rain or sewage) drainage;
Diameter: 300mm - 3600mm
Wall thickness: 1.5mm - 4.2mm
Anti-corrosion treatment: preservcotive (usually by coating asphalt or polymer coating)
We can provide comprehensive design and construction projects according to customer needs and site conditions.
Spiral Pipe Corrugated culvert have corrugation 68mm x 13mm, Corrugation 75mm x 25mm, Corrugation 125mm x 25mm
The minimum allowable depth of cover is the largest of:
For roads H=B/8+0.2(m) H=B/6(m) and not less than 0.6（m）
For railways H=B/4 and not less than 0.6(m)
There is a possibility to reduce depth of cover provided that suitable checking calculations will be made.
| Flexible structure | Plate thickness | Kinds of standard corrosion protection | Required average min value(um） |
| plates | ≧6mm | Hot zinc galvanizing | 85 |
| ≧3mm do < 6mm | Hot zinc galvanizing | 70 | |
| ≧1.5mm do < 3mm | Hot zinc galvanizing | 55 | |
| Bolts and nuts | - | Hot zinc galvanizing | 45 |
